500XL3

Pressure Reducing Valve

Lead Free

The 500XL3 Pressure Reducing Valve works effectively for industrial water lines and commercial-grade solution, with high-flow rate capacity and low falloff. The patented integral venturi enables the valve to have best in-class flow performance. The all-bronze body, stainless-steel stem and cartridge internals provide superior corrosion resistance and increases product life offering the ultimate value to the owner. It delivers high-flow performance with low pressure drop, making it ideal for demanding water distribution environments.

Where to Buy

PRV Calculator

Pressure_Reducing_Valve-Zurn_Wilkins-Model_500XL3_Less_Union-(212-3 _Inch).rfa

Pressure_Reducing_Valve-Zurn_Wilkins-Model_500XL3_Flanged-(212-4_Inch).rfa

Pressure_Reducing_Valve-Zurn_Wilkins-Model_500XL3_Single_Union-(1-2_Inch).rfa

500XL3_3D.dwgs.zip

1-4-500XL3_2D Drawings.zip

1-4-500XL3.dwf.zip

How to Use an RFA Family with a Type Catalog in Revit
Note: When downloading a Revit family, if a .txt file with the same name as the .rfa file is included, this indicates that the family uses a type catalog. In this case, follow the steps below to ensure Revit properly loads the predefined types.

Click here to view more instructions

Industry leading flow performance, durability, and premium materials of all direct-acting pressure reducing valves on the market
Delivers best-in-class flow performance of all direct-acting pressure reducing valves allowing for value engineered design optimization
Compact and shortest pressure reducing valve on the market allowing for installation versatility
Highly durable, all-bronze body resists corrosion and provides easy access to cartridge internals
Get smart pressure alerts with optional ZCSM-RP
Lead-free
ASSE® Listed
cUPC® Listed
CSA® Certified
Meets the requirements of NSF/ANSI/CAN 61 & 372
